DT 900 US diamond cutting blades, 20 x 9/64 x 1 Inch 36 segments 40 x 3,7 x 10 mm, narrow gullet
Call For Price
- Part Number: 334066
- UPC:
- Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Variations (4)
Product Overview
Info & Guides
Advantages: All-purpose high-performance tool - Extremely high cutting speed - Special segment bond for long service life and clean cuts - Engineered for professional use - Ideally suited for low-noise work environments thanks to sandwich core
Specifications
Details
Industrial Category:
Abrasives
Industrial Subcategory:
Abrasive Wheels, Discs and Brushes
Industrial Subtype:
Cut-Off and Grinding Wheels
Category Level 4:
Diamond and CBN Grinding Wheels
Aggression:
highest
Applicataion Areas:
Cured concrete, reinforced|Concrete, universal|Construction materials|Chalky sandstone|Granite
Application Area Defined:
Cured concrete, reinforced|Concrete, universal|Construction materials|Chalky sandstone|Granite
Bore Diameter (in):
1
Bore Diameter (mm):
25,4 mm
Core:
Sandwich core
Design:
Laser welded
Diameter (in):
20
Diameter (mm):
500
Gross weight:
4.2
Height Of Segments (in):
3/8
Height Of Segments (mm):
10 mm
Item Weight (LBS):
9.26
Length Of Segments (in):
1-1/2
Length Of Segments (mm):
40 mm
Machine Type:
table saw
Max. revolutions p.min.:
3900 U/min
Max. RPM:
3900 U/min
Number Of Segments:
36 St.
Order Minimum:
1
Output Dimensions (in):
Diameter x Bore - 20 x 1
Diameter x Bore - 500 x 25,4
Package Quantity:
1 ST
Package Volume (Cubic Decimeter):
2.6
Packaging Type:
cardboard box
Packaging UPC:
4014855275984
Segmentation:
Narrow gullet
Service life:
highest
Speed Limit (M/S):
100 m/s
Speed limit [m/s]:
100 m/s
Type of Use:
Table saw
UPC Number:
4014855275984
Version of Rim:
Narrow gullet
Version Of The Rim:
Narrow gullet
Width Of Segments (in):
9/64
Width Of Segments (mm):
3,7 mm
Other Details
All-purpose high-performance tool
ENGINEERED FOR PROFESSIONAL USE
Extremely high cutting speed
Ideally suited for low-noise work environments thanks to sandwich core
SPECIAL SEGMENT BOND FOR LONG SERVICE LIFE AND CLEAN CUTS
