PFERD COMBICLICK® CONTOUR Fiber Disc, 5" Dia, 120 Grit, Ceramic oxide CO-COOL
Call For Price
- Part Number: 64112512
- UPC: 04007220417041
- Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
Info & Guides
The COMBICLICK® system consists of a specially developed backing pad and a rugged mounting system at the back of the disc. The backing pad allows COMBICLICK® discs to be used on most available angle grinders. The special geometry of the cooling slots ensures high air throughput, which considerably reduces the thermal load on the abrasive material and the workpiece. The quick-mounting system, rugged fixture, secure attachment of the disc and optimized cooling system help to provide up to 30% lower workpiece temperature, up to 25% increased stock removal, up to 30% longer disc life and improved utilization of the abrasive. PFERD fibre discs are manufactured in accordance with ISO 16057 in shape A1 version F under the designation "vulcanized fibre disc". Very flexible and adaptable due to scalloped-edge outer contour shape. Helps prevent cutting into the workpiece. Active grinding additives in the coating substantially improve the stock removal rate, prevent loading, and result in cooler grinding.
Specifications
Details
Industrial Category:
Abrasives
Industrial Subcategory:
Abrasive Wheels, Discs and Brushes
Industrial Subtype:
Sanding Discs and Kits
Category Level 4:
Fiber Discs
Abrasive:
Ceramic oxide grain CO-COOL-CONTOUR
Applications:
Deburring
Applications 1:
Step-by-step fine grinding
Applications 2:
Leveling
Applications 3:
Surface work
Applications 4:
Work on weld seams
Applications 5:
Working on edges
Country of Origin:
DE
Customs Number:
6805100000
Diameter External (In):
5
Drive Types:
Angle grinder
Drive Types 1:
Cordless angle grinder
EAN:
4007220417041
EDP:
40802
Grit Size:
120 CONTOUR
Item Quantity:
25
Item Weight (kgs):
0.03
MANUFACTURER_TYPE_DESCR:
CC-FS 125 CO-COOL 120 CONTOUR
Materials that can be worked:
Annealed cast iron
Materials that can be worked 1:
Bronze
Materials that can be worked 2:
Cobalt-based alloys
Materials that can be worked 3:
Grey/nodular cast iron (GG/GJL, GGG/GJS)
Materials that can be worked 4:
Nickel-based alloys (e.g. Inconell and Hastelloy)
Materials that can be worked 5:
Stainless steel (INOX)
Materials that can be worked 6:
Titanium
Order Quanityt:
30
Pferdefficiency:
PFERDEFFICIENCY recommends COMBICLICK® for long, fatigue-free and resource-saving work in the shortest possible time. The patented quick-mounting system reduces disc changes and setup times.
Pferdergonomics:
PFERDERGONOMICS recommends COMBICLICK® as an innovative solution to reduce vibration, noise and dust produced during use and to improve comfort when working.
Prop 65:
View
Recommendations for use:
Use COMBICLICK® fibre discs with COMBICLICK® backing pads on commercially available angle grinders.
Recommendations for use 1:
Use the appropriate grinding oil for the material to significantly increase the service life and the abrasive performance of the discs.
Recommendations for use 2:
Use the CC-GT backing pad with M14 or 5/8" thread to maintain flexibility at the edge of the fibre discs.
Rpm, Max.:
12200
Safety notes:
The maximum permitted peripheral speed is 15,800 SFPM.
Safety notes 1:
For safety reasons, the maximum permitted rotational speed indicated must never be exceeded.
UNSPNC:
31191506
UPC Code:
97758408028
Other Details
Consistent surface finish resulting from high-quality abrasives.
Extremely quick and easy disc changes reduce process costs.
High productivity due to long service life and very high stock removal rate.
Innovative quick-mounting system guarantees convenient handling and cool grinding
With COMBICLICK®, scratches caused by protruding clamping parts are prevented and very high utilization of the available abrasive is attained.
