![3/4" Drive 6-Point SAE 15/16" Deep Socket](/vendors/7807/large/df57cb5a4e0b61ea0419f7105b8a11ca59c04151-large.png "3/4" Drive 6-Point SAE 15/16" Deep Socket")
3/4" Drive 6-Point SAE 15/16" Deep Socket
Call For Price
- Part Number: JHWHD-630
- UPC: 00662459230867
- Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
Info & Guides
3/4" Drive 6-Point SAE 15/16" Deep Socket
Specifications
Details
Industrial Category:
Hand Tools
Industrial Subcategory:
Sockets and Bits
Industrial Subtype:
Sockets
ANSI Number:
B107.110
Bolt clearance diameter (inches):
11/16
Country of Origin:
United States
Dimension A, Overall length (inches):
3-1/2
Dimension B, Drive End Diameter (inches):
1-7/16
Dimension C, Working End Diameter, inches:
1-3/8
Dimension D, Broach Depth, inches:
21/32
Dimension E, Bolt Clearance Depth, inches:
2-1/2
Dimension F, Nose Length, inches:
2-5/16
Drill Size (Inches):
3/4 inches
Finish:
High-Polished Chrome
Material:
Steel
Number of points:
6
OG1 Page:
307
Size (Inches):
15/16
Socket Type:
Deep Socket
System of Measurement:
SAE
Warranty:
Limited warranty; free from defects in workmanship and materials
Other Details
Designed for maximum engagement on 6 point fasteners
SUPERTORQUE lobular openings for greater turning power without deforming the fastener
